WIRELESS INTERFACES |
IX40-05: 5G NSA, 5G SA, 4G LTE-ADVANCED PRO CAT 19 |
5G NR bands: n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n71, n75, n76, n77, n78, n79;
4G LTE-Advanced Pro bands: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14 FirstNet®, B17, B20, B25, B26, B28, B29, B30, B32, B38, B40, B41, B42, B43, B46, B48, B66, B71;
3G bands: B1, B2, B3, B4, B5, B6, B8, B19 |
IX40-04: 4G LTE-ADVANCED PRO CAT 12, 3G HSPA+ |
4G LTE-Advanced Pro bands: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14 FirstNet®, B17, B18, B19, B20, B25, B26, B28, B29, B30, B38, B39, B40, B41, B42, B43, B48, B66, B71;
3G bands: B1, B2, B4, B5, B6, B8, B9, B19 |
CONNECTORS |
(2) or (4) 50 Ω SMA; center pin: female |
SIM SLOTS |
(2) Nano-SIM (4FF) holders |
SIM SECURITY |
SIM slot cover plate included |
TECHNOLOGY |
GPS Gen 9 with band L1 LNA for passive antenna use |
ANTENNA |
Upper L-band: GPS L1; Glonass G1; Beidou B1; Galileo E1
IX40-04: supports passive GNSS antennas rated at 1.5 to 3 dBi only
IX40-05: supports passive GNSS antennas rated at 1.5 to 3 dBi or active antennas with 7.5 to 26 dB gain |
PROTOCOL |
NMEA 4.11 and TAIP |
CONNECTOR |
(1) 50 Ω SMA; center pin: female |
WIRED INTERFACES |
PORTS / CONNECTOR |
(4) RJ-45; 10/100/1000 Mbps Base-T (auto-sensing); IEEE 802.3; configurable as WAN or LAN |
PORTS / CONNECTOR |
(2) Digital input/outputs; (2) analog inputs (0 - 10 V; 4 - 20 mA; 12-bit resolution) |
PORTS / CONNECTOR |
(2) 1 Gb capable SFP sockets |
PORTS / CONNECTOR |
(1) RS-232/422/485; DB-9 male (DTE) |
SOFTWARE & MANAGEMENT |
REMOTE MANAGEMENT |
Digi Remote Manager® (cloud based); SNMP v1/v2c/v3 (user installed/managed), SMS |
LOCAL MANAGEMENT |
Web UI (HTTPS); CLI (SSH, serial) |
MANAGEMENT TOOLS |
SFTP, SCP; protocol analyzer with PCAP for Wireshark; event logging with Syslog |
PROCESSOR |
APPLICATION PROCESSOR |
1.6 GHz quad-core i.MX 8M Plus ARM® Cortex®-A53 processor |
MEMORY |
RAM / FLASH |
1 GB / 8 GB |
PHYSICAL |
DIMENSIONS (L X W X H) |
234 mm x 154 mm x 41 mm (9.21 in x 6.06 in x 1.61 in) |
WEIGHT |
1.14 kg (2.51 lb) |
STATUS LEDS |
Power, WWAN, Ethernet (link, activity) |
ENCLOSURE/RATING |
Glass-filled polyphenylene sulphide / IP30 −40 °C to 85 °C (−40 °F to 185 °F) |
POWER REQUIREMENTS |
POWER INPUT |
12 to 30 VDC |
POWER CONNECTOR |
Screw down removable terminal block |
POWER CONSUMPTION |
4.5 W (light traffic), 8 W (peak data), 3.5 W (idle traffic) |
ENVIRONMENTAL |
OPERATING TEMPERATURE |
−30 °C to 70 °C (−22 °F to 158 °F) |
STORAGE TEMPERATURE |
−45 °C to 85 °C (−49 °F to 185 °F) |
RELATIVE HUMIDITY |
0% to 95% (non-condensing) at 25 °C (77 °F) |
APPROVALS* |
CELLULAR |
PTCRB, AT&T, FirstNet Capable™, T-Mobile;
visit product certifications for latest updates |
SAFETY |
IEC 62368-1, CB scheme |
EMISSIONS / IMMUNITY |
FCC Part 15 Subpart B, ISED, CE, RED, UKCA |
WARRANTY |
PRODUCT WARRANTY |
3-year* |
